Four valve lines, nine sizes each (Φ20–110mm), one matched system — made in our own facility to the same PN16 rating and material grade as the 806 UPVC pipe and fittings. Acid- and alkali-resistant, French brand, European-standard, serving 118+ countries.
A plastic line fails at the valve socket — a valve moulded from a different compound bonds differently, and the joint becomes the leak point. IFANNova manufactures standard ball valves, single-union, double-union and foot valves in the same facility, to the same PN16 rating and material grade as the 806 pipe and fittings, so importers, contractors and irrigation buyers source valves that mate to the line without a weak link.
For a hardware distributor, ball valves are among the fastest-turning SKUs on the shelf — but only if the assortment is complete. Every IFANNova UPVC valve line covers the full Φ20 / 25 / 32 / 40 / 50 / 63 / 75 / 90 / 110mm range, so you never ship a container with missing sizes. All lines are rated PN16 and joint with our UPVC solvent cement (125–1000ml range) — one adhesive across the whole system.
| Valve line | Series no. | Sizes | Handle / ends | Built for |
|---|---|---|---|---|
| UPVC Ball Valve 806 (Red / Blue Handle) | 1806-139~147 | 20–110mm (9 sizes) | Quarter-turn lever, solvent sockets | Volume retail & general isolation |
| Double Union Ball Valve | 1806-157~165 | 20–110mm (9 sizes) | Two detachable union ends | Pumps, filters, maintenance points |
| Single Union Ball Valve | 1806-166~175 | 20–110mm (9 sizes) | One detachable union end | Serviceable runs on a budget |
| Pump (Foot) Valve | 1806 series | 20–110mm (9 sizes) | Non-return + strainer end | Pump suction, irrigation intake |
| Full carton & weight data | Coming soon | Coming soon | Coming soon | Coming soon |
Every valve below shares the 806 socket dimensions, so it drops straight into the same UPVC line without adaptors. Solvent-cement or threaded ends; PN16.
Shown: the most-ordered types. Full item numbers, dimensions and carton quantities are in the catalogue — request the PDF.
Both are solvent-jointed once — the difference is what happens years later when the valve needs service. A union is a threaded collar you can unscrew by hand or wrench; where you place it decides whether maintenance means a spanner or a saw.
| Decision factor | Standard | Single union | Double union |
|---|---|---|---|
| Detachable ends | None | One | Two |
| Replace without cutting pipe | No | Partially | Yes — lift body out |
| Typical position | General isolation | One serviceable side | Pumps, filters, dosing, meters |
| Cost per point | Lowest | Middle | Cheapest over life at service points |
| Distributor note | Fastest-turning SKU | Niche but steady | Spec’d by name in project BOQs |
Rule of thumb: if a technician will ever need to remove that valve — pump stations, filter batteries, anything that clogs or wears — put a double union there. Everywhere else, the standard red/blue-handle valve keeps the bill of quantities lean.
A valve is the highest-stress point in a plastic line: it takes the same pressure as the pipe plus the mechanical load of operation. Every IFANNova UPVC valve is rated PN16 — the same class as the 806 pipe it joins — and the UPVC body is acid- and alkali-resistant, made from 100% high-standard raw material. We treat these as specs, not slogans — request the datasheet to verify pressure and media ratings against your duty.
Fertilizer, dosing and treatment lines where brass seizes and steel pits.
Foot valves sit permanently submerged in field-water; UPVC does not rust shut.
Acid / alkali transfer within the material’s rating — corrosion-free service.
The 806 material system is engineered for a 50+ year service life; the valves share it.
The most common failure in mixed-brand plastic lines is at the valve socket: a valve moulded from a different compound bonds differently, and the joint becomes the leak point. IFANNova valves are produced in the same facility (Zhuji Fengfan Piping, 10,000 moulds in-house), to the same material grade and PN16 rating as the 806 series 1806 UPVC pipe and fittings, and joint with the same UPVC solvent cement (125–1000ml).
One system means: one compatibility check instead of three, one container instead of three suppliers, and one factory answerable for the whole line. For drainage runs downstream of your valves, see our PVC drainage pipe & fittings.
IFANNova valves are produced under the same European-standard system as the full piping range, and our credential portfolio spans the certifications project engineers ask for by name — led by German SKZ, one of the industry’s strictest, alongside CE, WRAS, DVGW, SGS and ISO 9001 / 14001. For tenders that require certification to clear, this is the paperwork your consultant and the authority want to see before approval.
Certificate numbers, validity dates and covered product ranges: Coming soon — the certificate pack is available on request so your engineer can match each cert to the tender spec. Request the certificate pack for your spec →
Four valve lines, nine sizes each, red/blue-handle coding — load a complete assortment in one container, no missing SKUs, plus FOB pricing.
Valves matched to your 806 line — single vs double union spec’d by service point, same PN16 and material grade, no weak socket.
Acid/alkali-resistant foot valves for fertigation and pump suction — non-return holds the water column at pump stop.
1000+ employees · 24h online service · MOQ, lead time, monthly capacity & trade terms: Coming soon.
The four-line, nine-size model matrix (Φ20–110mm), the single vs double union selection guide, the foot-valve reference and an MOQ & FOB quick-sheet — everything to quote a UPVC valve order.
For the project contractor — a single union has one detachable end, a double union has two — unscrew both collars and the valve body lifts out without cutting the pipe. Spec double union at pumps, filters and any serviceable point; standard or single union everywhere else to keep the BOQ lean.
For the importer & distributor — yes — standard (red/blue handle), single union, double union and foot valve each cover Φ20/25/32/40/50/63/75/90/110mm, matching the 806 pipe range one-to-one. A container loads as a complete nine-size assortment per line, no missing SKUs on the shelf.
For the MEP & industrial buyer — our valves are moulded to the same material grade and PN16 rating as the 806 series 1806 pipe and fittings, in the same facility, and joint with our UPVC solvent cement (125–1000ml). Within one system the socket is not a weak point; for third-party pipe, request the datasheet to verify compatibility.
For the irrigation buyer — yes — the UPVC body is acid- and alkali-resistant, so fertigation and chemically dosed field water that pits metal foot valves is within its duty. The non-return function holds the water column at pump stop, protecting against dry restart. Verify your specific media concentration against the datasheet.
For the brand owner & distributor — yes — we offer private label across the valve range with your brand on handle, body and packaging, French brand and European-standard system behind your label. MOQ, trade terms and lead time: Coming soon — request current terms for your market and we confirm per order.
Tell us your valve mix (standard / single union / double union / foot valve), size range (Φ20–110mm), target market and quantity. We’ll send the size & model chart, MOQ, FOB pricing and the certificate pack — response within 24h.
